TD4174 4104 4185 tape

Description: It can perfectly replace models such as Dachser 4174, 4104, and 4185.

Characteristics: Matte soft PVC film, coated with weather-resistant rubber adhesive.It has moderate viscosity, good tearability, excellent temperature resistance, and leaves no residue.
Complies with RoHS 2002/95/EC.

Physical properties:

Thickness: 0.120±10% mm

Tensile strength: 1.8Kg/10mm

Color: Earthy yellow/green

Elongation: 150%

Adhesion: 0.16Kg/10mm

Temperature resistance: 170℃ for 1 hour

Based on the above characteristics, these tapes are highly suitable for the following scenarios:
• Automotive manufacturing: body painting, color segmentation, high-temperature masking in electrophoresis tank
• Precision industrial spraying: coating protection for aerospace components and electronic equipment casings
• High-temperature process scenarios: Protection for products that require baking or high-temperature curing.

Note: 1. For any special requirements beyond the above specifications, please contact our salesperson.
2. The data provided are average values (ASTM D 1000) and are for reference only. Users should confirm the

 applicability of the product.
3. The test subject is a PS TC standard steel plate. The performance of the test subject made of other materials needs

 to be confirmed by the user.
